Dataram DRS4800 User Manual
Dataram Hardware

CUSTOMER SUPPORT
Dataram's Technical Support Program goes beyond the lifetime warranty,
routine calls and questions. As memory specialists since 1967, we want
to provide the most comprehensive level of service and support in the
industry.
Our Customer Support representatives can answer your questions and
give you information on system/memory configurations, upgrade options,
product specifications, compatibility and other technical topics or issues.
In Europe:
+45 70 212 217 (Phone)
+45 70 212 211 (FAX)
(E-mail)
In the U.S.A. and all other countries:
800-599-0071 (Toll Free)
609-799-0071 (Phone)
609-799-6734 (FAX)
(E-mail)
If a Dataram memory board does not function properly we will issue a
Return Material Authorization number (RMA#) for the return of the
defective module(s) and express ship a repair or replacement to you at
no charge.
P/N 06675 C
P/N 06675 C
DRS280 and 4800 MEMORY INSTALLATION
INSTRUCTIONS FOR SUN FIRE MIDFRAME SERVERS
SUN FIRE 3800-6800, E2900, E4900 and E6900 SERVERS:
Note: Refer to your system owner’s manual for detailed instructions and be
sure to follow all static and safety precautions.
Memory for the Sun Fire Midframe servers is installed on one or more
UniBoard CPU/Memory Cards.
Location of the UniBoard CPU/Memory Cards:
Sun Fire
System
Max # of
UniBoards
CPU/Memory
Card Slot #’s
Location
3800 2 SB0,
SB2 Front
E2900
3
SB0, SB2, SB4
Top
4800, E4900
3
SB0, SB2, SB4
Rear
4810
3
SB0, SB2, SB4
Front
6800, E6900
6
SB0-SB5
Front
Each UniBoard has 32 DIMM slots, which are divided into eight banks of
four. Each processor controls two banks.
When installing multiple sets of memory, fill both banks for each processor
before installing any remainder as a bank of four.
Each slot has a three-digit label. The first digit indicates the corresponding
processor (0-3), the second indicates the bank (0 or 1), and the third
indicates the DIMM slot (0-3).
DIMMs can only be installed where there is a corresponding processor.
CUSTOMER SUPPORT
Dataram's Technical Support Program goes beyond the lifetime warranty,
routine calls and questions. As memory specialists since 1967, we want
to provide the most comprehensive level of service and support in the
industry.
Our Customer Support representatives can answer your questions and
give you information on system/memory configurations, upgrade options,
product specifications, compatibility and other technical topics or issues.
In Europe:
+45 70 212 217 (Phone)
+45 70 212 211 (FAX)
(E-mail)
In the U.S.A. and all other countries:
800-599-0071 (Toll Free)
609-799-0071 (Phone)
609-799-6734 (FAX)
(E-mail)
If a Dataram memory board does not function properly we will issue a
Return Material Authorization number (RMA#) for the return of the
defective module(s) and express ship a repair or replacement to you at
no charge.
P/N 06675 C
P/N 06675 C
DRS280 and 4800 MEMORY INSTALLATION
INSTRUCTIONS FOR SUN FIRE MIDFRAME SERVERS
SUN FIRE 3800-6800, E2900, E4900 and E6900 SERVERS:
Note: Refer to your system owner’s manual for detailed instructions and be
sure to follow all static and safety precautions.
Memory for the Sun Fire Midframe servers is installed on one or more
UniBoard CPU/Memory Cards.
Location of the UniBoard CPU/Memory Cards:
Sun Fire
System
Max # of
UniBoards
CPU/Memory
Card Slot #’s
Location
3800 2 SB0,
SB2 Front
E2900
3
SB0, SB2, SB4
Top
4800, E4900
3
SB0, SB2, SB4
Rear
4810
3
SB0, SB2, SB4
Front
6800, E6900
6
SB0-SB5
Front
Each UniBoard has 32 DIMM slots, which are divided into eight banks of
four. Each processor controls two banks.
When installing multiple sets of memory, fill both banks for each processor
before installing any remainder as a bank of four.
Each slot has a three-digit label. The first digit indicates the corresponding
processor (0-3), the second indicates the bank (0 or 1), and the third
indicates the DIMM slot (0-3).
DIMMs can only be installed where there is a corresponding processor.
