DRI615 and DRI550 MEMORY
INSTALLATION INSTRUCTIONS
SYSTEM AND MEMORY OVERVIEW
Note: Refer to your system owner’s manual for detailed instructions and be
sure to follow all static and safety precautions.
• The DRI615 and DRI550 memory upgrades are available in various
capacities for a number of IBM systems:
• Each DRI615 and DRI550 upgrade consists of four identical DIMMs.
• The pSeries 615 has 8 DIMM slots (2 banks of 4) located on the
backplane.
• The OpenPower 710 and p5 9110-510 have 8 DIMM slots (2 banks
of 4) located on the backplane.
• The OpenPower 720 and p5 9111-520 have 8 DIMM slots (2 banks
of 4) located on the backplane.
• The p5 9113-550 DIMM slots are located on the two Processor
Cards, each containing 8 DIMM slots (2 banks of 4).
• The IntelliStation POWER Workstation 9114-275 has 8 DIMM slots
(2 banks of 4) located on the backplane.
