Page 3
5FJ-P 8/08
OUTSIDE OF SHOWER
HKMAGCH
MAGNETIC
CATCH KIT
A993
MAGNETIC DOOR STOP
V678
VINYL DOOR SEAL
H470 TRUSS
HEAD SCREW
HA75
METAL
SLIDE
A855
SILL
A
A942
JAMB
V001
VINYL DRIP
SWEEP
H002
ANCHOR
H470
TRUSS HEAD SCREW
L
F
F
V
H475
PAN HEAD
SCREW
A101
HEADER
K
K
C
D
S
B
PUSH/PULL
HANDLE
KIT
E
J
8A x 3/8 Truss Head Screw
(H470 - Used for securing Magnetic
and Hinge Door Stops)
K
8A x 1 Pan Head Screw
(H475 - Used for Jambs)
J
Care should be taken when standing raw glass on its edge. Glass may shatter if corners are bumped or edge is
rested on a rough floor surface. Cardboard, wood blocks, or a similar surface is a safe resting surface for glass.
