Coral Industries 6000 Bypass with ATB Towel Bar - 26X1-G User Manual
26x1, 6000 series • bypass enclosure, Tools needed

26X1 1/99
26X1
6000 Series • Bypass Enclosure
(ATB / ATH)
DESCRIPTION
PART
A
SILL
A925
1
1
B
JAMB
A901
2
2
C
HEADER
A900
1
1
D
TOWEL BAR
A721
2
1
J
VINYL TRACK GUIDE
V145
1
1
E
TOWEL BAR BRACKET KIT
HBAB
1
8A X 1 PAN HEAD SCREW
H479
2
8A X 1 1/4 FLAT HEAD SCREW
H810
2
PULL STOP
HA12
2
TOWEL BAR BRACKET
HA14
4
L
TOWEL BAR/PULL HANDLE KIT
HBAH
1
8A X 1 PAN HEAD SCREW
H479
2
PULL/STOP
HA12
2
PULL HANDLE
HA16
2
TOWEL BAR BRACKET
HA14
2
8A X 1 1/4 FLAT HEAD SCREW
H810
2
F
ROLLER
H342
4
4
K
8-32 X 3/8 TRUSS HEAD SCREW
H430
4
4
G
GUIDE
V494
1
1
H
8A X 1 1/4 PAN HEAD SCREW
H480
6
6
I
BUMPER
HB01
4
4
M
ANCHOR
H002
6
6
O
8A X 3/8 PAN HD SELF DRILLING SCR
H901
3
3
KEY
STANDARD
UNIT
TOOLS NEEDED
1/8" Drill Bit
3/16" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Scratch Awl
Measuring Tape
Hacksaw
Phillips Screw Driver
Caulking Compound
File
Drill
Level
Masking Tape
A901
JAMB
A925
SILL
A721
TOWEL BAR
V145
VINYL TRACK GUIDE
A900
HEADER
HBBB
TOWEL BAR
BRACKET KIT
A
B
C
D
J
H810
FLAT HEAD
SCREW
HA12
PULL/STOP
E
H342
ROLLER
F
G
H901
PAN HEAD
SELF DRILLING
SCREW
V494
GUIDE
H480
PAN
HEAD
SCREW
H002
ANCHOR
O
M
H
I
HB01
BUMPER
K
H430
TRUSS HEAD SCREW
MIRROR
UNIT
OUTSIDE OF SHOWER
H901
PAN HEAD SELF
DRILLING SCREW
O
H479
PAN HEAD
SCREW
HA14
TOWEL
BAR
BRACKET
FRAME PACKAGE
HARDWARE BAG PARTS
