Coral Industries 6000 Bypass with Oval Towel Bar - 2681-G User Manual
2681-g, Bypass enclosure, Tools needed

2681-G 11/06
2681-G
Bypass Enclosure
DESCRIPTION
PART
STANDARD
UNIT
A
SILL
A925
1
1
B
JAMB
A901
2
2
C
HEADER
A902
1
1
D
TOWEL BAR
A159
2
1
J
VINYL TRACK GUIDE
V436
1
1
E
TOWEL BAR BRACKET KIT
HB0L
1
8-32 X 3/4 TRUSS HEAD SCREW
H440
2
TOWEL BAR BRACKET
H020
4
PULL/STOP
HA12
2
8-32 X 1 TRUSS HEAD SCREW
HS10
2
PULL STOP LABEL
H904
2
L
TOWEL BAR / PULL HANDLE KIT
HB0H
1
PULL HANDLE
HA16
2
TOWEL BAR BRACKET
H020
2
8A X 1 PAN HEAD SCREW
H479
2
8-32 X 3/4 TRUSS HEAD SCREW
H440
2
F
ROLLER
H342
4
4
K
8-32 X 3/8 TRUSS HEAD SCREW
H430
4
4
G
GUIDE
HA21
1
1
H
BUMPER
HB01
4
4
I
8A X 1 1/4 PAN HEAD SCREW
H480
6
6
M
ANCHOR
H002
6
6
N
8A X 3/8 PAN HEAD SELF-DRILLING SCREW
H900
3
3
TOOLS
NEEDED
1/8" Drill Bit
3/16" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Scratch Awl
Measuring Tape
Hacksaw
Phillips Screw Driver
Caulking Compound
File
Drill
Level
Masking Tape
KEY
A901
JAMB
A925
SILL
A902
HEADER
HA12
PULL/STOP
H342
ROLLER
H901
PAN HEAD
SELF DRILLING
SCREW
HA21
GUIDE
H002
ANCHOR
H430
TRUSS HEAD SCREW
OUTSIDE OF SHOWER
M
N
F
A159
TOWEL BAR
V436
VINYL TRACK
GUIDE
HBOL
TOWEL BAR
BRACKET KIT
H480
PAN
HEAD
SCREW
K
E
J
I
C
FRAME PACKAGE
HARDWARE BAG PARTS
D
H901
PAN HEAD SELF
DRILLING SCREW
HB01
BUMPER
A
H904
PULL STOP
LABEL
HS10
TRUSS HEAD
SCREW
H440
TRUSS HEAD
SCREW
TOWEL BAR
PULL HANDLE
UNIT
B
N
G
H
t
