Coral Industries 7000 Swing Door - 640 User Manual
7000 series • swing door, Frame package parts hardware parts, Tools needed
640 (70A) 7/09
640
7000 Series • Swing Door
(GIH / AHD)
A
SILL
A001
1
B
JAMB
A083
2
C
MAGNETIC DOOR STOP
A989
1
D
DRIP RAIL
A710
1
DRIP RAIL SWEEP **
VS91
1
DRIP RAIL TAPE **
HT52
1
G
MAGNETIC STRIP
H170
1
H
PULL HANDLE KIT *
HSAD
6-32 X 1 1/4 PAN HEAD SCREW
H485
2
EXTERIOR PULL HANDLE
HA31
1
INTERIOR PULL HANDLE
HA32
1
I
8A X 1 1/4" PAN HEAD SCREW
H480
6
J
8A X 3/8" PAN HEAD SCREW SELF DRILL
H900
10
K
ANCHOR
H002
6
L
DRIP RAIL PLUG
HA28
1
DESCRIPTION
KEY
PART
QTY
FRAME PACKAGE PARTS
HARDWARE PARTS
OUTSIDE OF SHOWER
* May be pre-installed
** Pre-installed
TOOLS NEEDED
1/8" Drill Bit
3/16" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Scratch Awl
Measuring Tape
Hacksaw
Phillips Screw Driver
Caulking Compound
File
Drill
Level
Masking Tape
H002
ANCHOR
K
A001
SILL
A
A710 DRIP RAIL
ASSEMBLY
D
H
HSAD
PULL HANDLE KIT
A083
JAMB
B
A989
MAGNETIC
DOOR STOP
H480
PAN HEAD
SCREW
J
H900
PAN HEAD
SCREW
G
HA28
DRIP
RAIL
PLUG
L
H170
MAGNETIC
STRIP
HA32
INTERIOR
HANDLE
H485
PAN
HEAD
SCREW
HA31
EXTERIOR
HANDLE
I
C
