Coral Industries 6000 Neo-Angle Swing Door (EZ Up) - 84K - Manual (Page 2)

84K-GP 3/07
Before starting installation of your new enclosure, carefully read all instructions
and lay out parts to become familiar with their identity.
USE OF ANCHORS
Anchors are furnished with every enclosure. However, the use of anchors is not recommended when attaching your enclosure
to a fiberglass unit or wall surround with board reinforced mounting areas. Mounting holes in this case should be drilled with
an 1/8" drill bit.
Mounting this unit on tile requires the use of anchors. Special care must be taken not to crack the tile. Before drilling holes in
the tile, lightly chip glazed surface of tile at the desired locations. Drill holes using a 3/16" masonry drill bit. Insert anchors into
the holes making certain that ring on large end of anchor meets the surface of the tile.
CLEANING
SEALING
The use of a caulking compound can assure a water-tight seal when applied along outside edge of the enclosure where metal
and bath meet. If desired, caulk inside of enclosure where jambs meet walls.
C leaning and care of your enclosure is important to its lasting beauty. A nonabrasive liquid cleaner is recommended.
Never use scouring powder or pads.
Do not try to cut the mirrors or glass used in this enclosure.
Tempered glass and mirrors will disintegrate if cut.
PARTS LIST
KEY DESCRIPTION PART QTY
A SIDE PANEL 2
B DOOR PANEL / CORNER POST 1
C JAMB A310 2
D DRIP RAIL A710 1
E DRIP RAIL SWEEP VS91 1
F DRIP RAIL TAPE (I) HT52 1
G 8A X 3/8 TRUSS HEAD SCREW H470 6
H 8A X 3/4 FLAT HEAD SCREW H467 6
I 8A X 1 1/4 PAN HEAD SCREW H480 6
J ANCHOR H002 6
K DRIP RAIL PLUG HA28 1
L CLEAR CORNER BRACE * HB13 2
M 8A X 5/8 PAN HEAD SELF-DRILLING SCREW * H437 4
N PULL HANDLE KIT + HSAD 1
EXTERIOR PULL HANDLE HA31 1
INTERIOR PULL HANDLE HA32 1
6-32 X 1 1/4 PAN HEAD SCREW H485 2
FRAME PACKAGE
HARDWARE BAG
* Optional (I) Pre-Installed (+) May be Pre-Installed
1/8" Drill Bit
3/16" Drill Bit
(3/16" Masonry Bit for
Ceramic Tile)
Measuring Tape
Phillips Screw Driver
File
Drill
Level
China Marker
Caulking Compound
TOOLS
NEEDED
