Appendix – BoonDocker EBC User Manual
Page 8
BoonDocker Performance 2379 W. Heyrend Way Idaho Falls, ID 83402
Toll Free (US) 877-552-6127 or 208-542-4411 www.boondockers.com
Revised 10-28-11 Electronic Boost Controller install/operation instructions
Page 8
Appendix
Kit Contents list for Arctic Cat M8 and M1000 (2011 and Older):
1- Electronic Boost Controller (EBC)
2- 24” length x 1/8” O.D. Poly line
1- Boost Solenoid
24” length x 3/16” I.D. vacuum line
1- Mounting bracket (Velcro)
4- small zip ties
1- Handlebar Push Button (optional)
4- large zip ties
1- Push-to-Connect Y
1- Push to connect 90
1- Arctic Cat EBC Harness (w/6 pin connector)
1- ADA harness (w/10 pin connector, only for use with Boondocker Fuel Control Box)
Kit Contents list for Polaris Dragon:
1- Electronic Boost Controller (EBC)
24” length x 1/8” O.D. Poly line
1- Boost Solenoid
30” length x 3/16” I.D. vacuum line
1- Mounting bracket
4- small zip ties
1- Polaris Handlebar Push Button (optional)
4- large zip ties
1- Polaris EBC Harness (w/6 pin connector)
1- ¼-20 x 1” bolt and lock washer
1- ADA harness (w/10 pin connector, only for use with Boondocker Fuel Control Box)
1- Push to connect 90
Kit Contents list for 2011 Polaris RMK:
1- Electronic Boost Controller (EBC)
36” length x 1/8” O.D. Poly line
1- Boost Solenoid
24” length x 3/16” I.D. vacuum line
1- Mounting bracket
4- small zip ties
1- Handlebar Push Button (optional)
4- large zip ties
1- ’11 RMK EBC Harness (w/6 pin connector) 2- Small self-tapping screws
1- ADA harness (w/10 pin connector, only for use with Boondocker Fuel Control Box)
1- Push to connect 90
Kit Contents list for Polaris RZR:
1- Electronic Boost Controller (EBC)
96” length x 1/8” O.D. Poly line
1- Boost Solenoid
48” length x 3/16” I.D. vacuum line
1- Mounting bracket (dash mount)
4- small zip ties
1- Handlebar Push Button (optional)
4- large zip ties
1- Polaris EBC Harness (w/6 pin connector)
1- #28 Hose clamp
2- #4 hose clamps
1- 7’ EBC harness extension
1- Turbo transducer harness (w/10 pin connector, only for use with Boondocker Fuel Control Box)
1-Push to connect 90
