Revised 10-28-11 Electronic Boost Controller install/operation instructions Page 2
Installation (continued)
Attach the electronic boost controller (EBC) mounting bracket to a convenient location on the console or
handlebars. Slide the EBC onto the bracket.
Connecting the EBC harness to power is different for every sled:
For Polaris Dragon, the EBC harness plugs into accessory power near the top of the firewall.
This connector has a red/white and brown wire. Be sure that the molded rubber EBC connector
having the male pin with the red wire plugs into the sled harness, aligning with the red/white
wire. The other EBC connector having the female pin with the red wire can be used for the oil
pump and/or fan. Be sure that red (or red/white) wires go to red wires and brown wires go to
brown wires.
For Polaris RMK Pro, the EBC harness plugs into accessory power under the left side panel. It
is the white connector labeled “DC Power”.
For Polaris RZR, the EBC harness plugs into the accessory power provided by the relay that
powers the intercooler fan. Be sure that the molded rubber EBC connector having the male pin
with the red wire plugs into the relay harness so the colors line up. The other mating rubber
molded connector with the pin with the brown wire that is exposed will plug into the fan wiring
harness. The two position connector with the brown and blue wires will plug into the new
supplied turbo harness going to the fuel control box. This will provide the boost pressure signal
to the fuel control box.
For Arctic Cat M8 and M1000 WITHOUT a fuel pump booster, unplug the fuel pump at the
right side of the firewall and plug the EBC harness in line so that all the black connectors are
used.
For Arctic Cat M8 and M1000 WITH a fuel pump booster, only the fuel booster connects in
line between the fuel pump and its power connector. DO NOT CONNECT THE EBC IN
LINE WITH THE STOCK HARNESS. DO NOT PLUG THE EBC INTO THE FUEL
BOOSTER CONNECTOR WITH THE RED AND BLACK WIRES. One of the black
connectors on the EBC harness plugs into the extra connector on the fuel pump booster. The
other black connector on the EBC harness is used only for the optional auxiliary injectors. DO
NOT ATTEMPT TO USE POWER FROM THIS CONNECTOR OR FROM THIS
POWER CIRCUIT FOR ANY OTHER PURPOSE.
The rest of the connections are the same for every sled:
Attach the handlebar button in a convenient location on the left side of the handlebar and plug it
into the EBC harness. This is your Push-to-Pass button. According to your Plus HP button
setting (SET +HP), this gives more boost when the button is pressed. Plug this button into the
mating connector on the EBC harness.
Plug the EBC harness into the boost solenoid. Plug the 6-pin connector of the EBC harness into
the EBC pigtail.
