Salter Brecknell 308BP User Manual
Page 15
xv
NAME/CODE
DESCRIPTION
CODE/VALUE
A1
Baud Rate
Selects the baud rate for data transmission through the serial port.
600
1200 2400
4800
9600√
√√√
A2
Data Bits and
Parity
Selects the number of data bits and parity of serial transmission.
"8n" = 8 data bits with no parity bit and one stop bit
"7O" = 7 data bits with odd parity bit and one stop bit
"7E" = 7 data bits with even parity bit and one stop bit
8n√
√√√
7O
7E
A3
Mode of Serial
Transmission
Selects when data will be sent out of the serial port to a printer or
computer:
"C" = Continuous mode; send data continuously
"d" = Demand mode; send data when a PRINT command is issued
from the computer.
C
d√
√√√
A4
Display Check
Actuates the function that illuminates all digit segments, decimal
points, and LCD annunciators in a test sequence. Pressing the
SAMPLE
key to scroll down one level begins the test sequence.
Press
SAMPLE
key to begin
sequence
A5
Auto Power Off
Period
Selects the auto off time period in minutes. Scale must be idle during
this period to shut off automatically.
"OFF" = Feature Disabled
OFF√
√√√
1
5 10
15 20
30
A6
Units Selection
Actuates the function that allows customization of the displayed
weight units. Pressing the
SAMPLE
key to scroll down one level
begins the sequence.
Press
SAMPLE
key to begin
sequence
A7
Custom Unit
Actuates the function that allows setup of the custom unit. Pressing
the
SAMPLE
key to scroll down one level begins the sequence.
Press
SAMPLE
key to begin
sequence
A8
Serial Port
Mode
Selects the mode of the RS-232C serial port:
"0" = Full Duplex Mode
"1" = APW Transmit Mode
0√
√√√
1
Table 5-1: User Menu Chart
5.2.4 UNITS SELECTION PROCEDURE (A6)
1. While in the A6.sub-menu, press the MR key. The scale illuminates the lb annunciator and
displays the current status (ON or OFF) of the lb unit.
2. Use the PRINT key to toggle the status of the unit from ON to OFF.
3. Use the SAMPLE key to toggle among the available weight units.
4. Repeat Steps #2 and #3 until you have programmed all units.
5. Press the UNITS key to save all of your new settings and return back to the A6 sub-
menu prompt.
