B&M 45034 PRECISION SPORT SHIFTER - 08 & UP CORVETTE C6 & Z06 - Manual (Page 7)

STEP B. Remove bolts (2) securing shifter base to vehicle.
TOOLS: Ratchet, Extension, T-40 Torx Socket
STEP C. Remove stock rubber bushings and spacer.
TOOL: Small Flatblade Screwdriver
NOTE: The following steps are to install the optional spacer and
washer that is provided in the kit. A much more solid shifting feel
is obtained if installing the provided spacer and washer because
it replaces the much softer stock bushings. These steps are not
necessary on Z06 model vehicles as it is already solid mounted.
IMPORTANT: The installation of the spacer and washer will
transmit more noise and vibration than the softer rubber bush-
ings. If a quieter and less vibration transmitting shift quality is
preferred over a more solid and direct shift feel, then DO NOT
proceed with these optional (A-F) installation steps.
OPTIONAL INSTALLATION
STEP A. See top-right picture for indication of working area.
Remove "L" pin from the stock shifter. With the shifter
still in neutral and E-brake in the ON position, insert
the "L" pin into the pin hole of the shifter base. The "L"
pin is used to keep everything aligned. If done
correctly, shifter should not be able to shift
out of neutral position.
Stock Rubber Bushing
Transmission
Shifter Base Pin Hole
Press "L" pin down into
shifter base pin hole
"L" pin
on stock shifter
