AVer SF2121H Series User Manual

Page 20

Text mode
Original mode

*(1)

(2)
(3)
(4)
(5)
(6)

(7)

Name

Function

(1) Sensor Mode

Select sensor input resolution from either Normal or Wide Angle.
* ( Available for 3M pixel or above model )

(2) Stream Type

Select to transmit single or simultaneous multiple streams of 2 or
3 videos.

(3) Stream

Select the streaming source.

(4) Region of Interest

Select the cropping size of video.

(5) Output Resolution

Select the video size.

(6) Frame Rate

Select frame rate per second of video

(7) Code Type

Select the type of video compression codec. The supported
codec is H.264, MPEG4, and MJPEG. On each stream, adjust
rate control and video quality setting.
