AVer SF2121H Series - Manual (Page 17)

17
Name Function
(1) Exposure Area Select the exposure area choices to define the light distribution and
bring out more details.
Entire screen - measure the entire screen to adjust the exposure.
Customize - measure the exposure to where the adjustable and
movable frame on the screen is located. Move the spot to dark
zone to adjust the light condition.
Backlight compensation - measure the exposure at the center of
the screen.
(2) Exposure Mode Select to automatically or manually adjust the exposure.
Auto - adjust exposure level from -2.0 to +2.0
Manual - adjust max shutter and gain control
S y s t e m > I m a g e > Ad v a n c e d
In Advanced tab, you can configure the Wide Dynamic Range, Denoise, IR-Cut Filter, and
B/W image at night. After completing the setting, click Save to apply the new setting and
Cancel to keep the old setting.
(5)
(1)
(2)
(3)
(4)
