Function Description
Shuttle Wheel mode, or to make a selection and adjustment on the
OSD main-menu and sub-menu (See Menu
Functions for more details).
(5) ENTER Make a selection in Playback mode and OSD menu.
Use this to quick zoom to 200% or back to 100% in
Camera mode only.
(6) FREEZE Toggle to pause or resume the camera.
(7) MENU Pull up and exit the OSD main-menu and sub-menu.
(8) PLAYBACK View the captured image from the memory in
16-thumbnail images.
Use ▲,▼,◄, & ► to make a selection and ENTER to
view the selected image in full screen. To zoom in and
out the image, turn the shuttle wheel clockwise and
counter-clockwise.
To start slide show, press MENU, select START and
press ENTER to begin and end. Select INTERVAL to
set the display time interval between frames in
second.
To change the slide show time interval, select
INTERVAL, press ENTER and the bar will turn red,
use ◄ & ► to increase and decrease the value, and
then press ENTER to save the setting and the bar will
turn white.
SLIDE SHOW
START
INTERVAL
10 1 1
(9) CAMERA/PC Switch between Camera and PC mode.
- Camera mode displays the video signal from the
built-in camera.
- PC mode displays the video signal from the RGB
INPUT port of CP355.
(10) AUTO FOCUS Adjust the focus automatically.
(11) AUTO IMAGE Automatically adjust and set the white balance and
exposure setting.
(12) CAP/DEL - Capture a still image in Camera mode. The captured
image is saved in the memory and can store up to
80 images. The image size can be saved either in
1024 x 768 (default) or 2016 x 1520 pixels.
If the Capture setting is in Continuous mode, use
CAP/DEL button to start and stop successive still
image capture. To stop continuous capture, press
CAP/DEL button when “SAVE” message in the
status box at the lower right corner of the screen
disappear.
To set the image size of your choice, press MENU,
select CAPTURE in IMAGE menu list, press
ENTER, select IMG SIZE, press ENTER, use ▲ and
16
