Alumax P-DRC1Y User Manual
Page 26

26
THRESHOLD INSTALLATION
13
COUPER SELON L’OUVERTURE
AVEC UNE SCIE À MAIN
SILICONE
14
HOURS
Cut the threshold (13) to the necessary
opening ensuring optimal water retention.
Proceed to applying a bead of silicone to
the underside of the threshold and placing it
on the threshold of the base.
S
13
13
13
Apply silicone (S) between the bottom of the
xed panel and the threshold of the base. This
is done from the outside of the shower area.
