PANNEAU FIXE / FIXED PANEL 1
CONFIGURATIONS AND PARTS LISTING ..................... 3,4,5,6
PROVIDED HARDWARE ............................................... 7
REQUIRED TOOLS AND MATERIALS ................................. 7
DOOR PANEL PLACEMENT ........................................... 8
COMPONENTS INSTALLATION. ...................................... 8
FIXED PANEL AND RETENTION GASKET ............................ 9
FIXED PANEL PLACEMENT .................................. 10,11,12
TOP ROLLERS INSTALLATION ....................................... 12
DOOR PANEL PLACEMENT .......................................... 13
BOTTOM ROLLERS INSTALLATION ................................. 13
STRAIGHT HANDLE .................................................. 14
GASKETS INSTALLATION ............................................ 14
STOPPERS ADJUSTMENT ............................................ 15
SILICONE .............................................................. 15
TABLE OF CONTENTS
GENERAL INSTRUCTIONS
- Read this manual carefully and completely before
proceeding.
- t c u d o r P are subject to change without no-
tice. Use the installation instructions supplied with the
product.
● WATERPROOFING
- No sealant is required inside the shower.
- All models are equipped with transparent sealing gaskets.
- For models with wall jambs, if your shower door is to be
installed over ceramic tiles, the tiles should lay completely
under the wall jambs.
● MAINTENANCE
- Never use scouring powder pads or sharp instruments on
metal pieces or glass panels.
- An occasional wiping down with a mild soap diluted in water
is all that is needed to keep the panels and aluminum parts
looking new.
- We recommend wiping the glass panels with a squeegee after
each use.
● SAFETY
- It is recommended that you wear safety glasses at all times
during the installation.
- At all times, 2 people are required for this installation.
