SHUTTER SPEED/APERTURE FOR EACH EXPOSURE MODE IN TTL AUTO FLASH
In Matrix Metering (with 50mm f/1.4 lens at ISO 100)
bear
..[
n
W
ma
3
la
C «np)
)
HEAfl,,fNQR>^_________ |ALMJf)jjTTLl
( CUBP (t (
jiim
I
p
) )
Speedlight
Front-curtain sync (NORMAL)
Rear-curtain sync (REAR)
Exposure mode
iing^
PD*/P/PH
1/60-1/250 f/4-f/16(1)
1/60-1/250 f/4-f/16(1)
30-1/250 f/4-f/16(1)
30-1/250 f/4-f/16(1)
S
As set (3) f/2.8-f/16 (2)
Asset (3) f/2.8-f/16(2)
As set (3) f/2.8-f/16 (2)
As set (3) f/2.8-f/16 (2)
A
1/60-1/250 As set
1/60-1/250 As set
30-1/250 As set
30-1/250 As set
M
As set (3) As set
As set (3) As set
As set (3) As set
As set (3) As set
*F-801/N8008 only.
I': Matrix Balanced Fill-Flash (background correctly exposed; TTL flash level automatically compensated)
I I: Standard TTL flash (background correctly exposed)
■ '
(1) Maximum usable aperture varies according to film speed in use; minimum aperture is the smallest aperture of the lens in
use. With the F4, aperture is automatically controlled between the lens' maximum aperture to its minimum.
(2) Maximum usable aperture is f/2.8; minimum aperture is the smallest aperture of the lens in use. With the F4, aperture is
automatically controlled between the lens’ maximum aperture to its minimum.
(3) When set from 1/500 to 1/8000 sec., the shutter is automatically set to 1/250 sec.
49
