Index to parts and controls
Refer to the pages indicated in parentheses ( ) for details.
Front panel
rn l/Cl) POWER switch/indicator (67)
Remote sensor (5)
(3l Tape compartment
[4] REJECT button (60)
[5]
REW (rewind) button (60, 73)
H] [> PLAY button (60, 73)
0
FF (fast-forward) button (60,
73)
[8] • REC (record) button (63, 78, 87)
[9] ■ STOP button (60, 87)
El II PAUSE button (60, 87)
Ej] CHANNEL/TRACKING+/-
buttons (63, 83)
El EASY SET UP button (12, 16, 20, 24,
28, 31)
El LINE-2 IN VIDEO / AUDIO L / R
jacks (86)
94
