Specifications
MONITOR OUT
VIDEO (phono jack): 1 Vp-p,
75-ohms unbalanced, sync
negative
AUDIO (phono jacks): 500 mVrms
(100% modulation),
Impedance: 5 kilohms
AUDIO OUT (phono jacks): 500
mVrms (100% modulation)
Impedance: 5 kilohms
Projection system 3 picture tubes, 3 lenses,
horizontal in-line system
Picture tube 7 inch high-brightness
monochrome tubes (6.3 raster
size), with optical coupling and
liquid cooling system
Projection lenses High performance, large-
diameter hybrid lens Fl.l
Screen size (measured diagonally)
Speaker
Speaker output 12 W x 2
Power requirement
Full range speaker 100 mm (3.9
inches) diameter
Television system American TV standards
Channel coverage VHF; 2 -13 / UHF: 14 - 69 /
CATV: 1 -125
Antenna
InputS/òutput
75 ohm external antenna
terminal for VHF / UHF
VIDEO IN 1
VIDEO IN 2 (VIDEO 2 INPUT)
S VIDEO (4-pin mini DIN):
Y: 1 Vp-p, 75-ohms
unbalanced, sync negative
C: 0.286 Vp-p (Burst signal)
75 ohms
VIDEO (phono jack): 1 Vp-p,
75-ohms unbalanced, sync
negative
AUDIO (phono jacks): 500
mVrms (100% modulation)
Impedance : 47 kilohms
VIDEO IN 3
VIDEO (phono jacks): 1 Vp-p,
75-ohms unbalanced, sync
negative
AUDIO (phono jacks): 500
mVrms (100% modulation)
Impedance: 47 kilohms
For KP-41T65C/53S65C/61S65C:
220 V AC, 50/60 Hz
For other models: 120 V AC,
60 Hz
KP-41T65 41 inches
KP-41T65C 41 inches
KP-46C65 46 inches
KP-48S65 48 inches
KP-53S65 53 inches
KP-53S65C 53 inches
KP-61S65 61 inches
KP-61S65C 61 inches
Power consumption
165 W
Standby mode: 2.5 W
Dimensions(W/H/D) Mass
KP-41T65 951 X 1,022 X 602 mm
(37'/2X40 ' / 4 x 2 3 V 4 inches)
55 kg
(121 lbs 4 oz)
KP-41T65C 951 X 1,022 X 602 mm
(37 ' /: X 40 '/ 4 X 23 V 4 inches)
55 kg
(121 lbs 4 oz)
KP-46C65 1,066 X 1,306 X 563 mm
(42 X 51 ' /
2 X 22 ' / 4 inches)
65 kg
(143 lbs 5 oz)
KP-48S65 1,106 X 1,337 X 571 mm
(43 Vs X 52 Vs X 22 '
/ 2
inches)
67 kg
(147 lbs 11 oz)
KP-53S65 1,218 X 1,413 X 614 mm
(48 X 55 V« X 24
' / 4
inches)
69 kg
(152 lbs 1 oz)
KP-53S65C 1,218x1,413x614 mm
(48
X 55 V« X 24 ' /
4
inches)
69 kg
(152 lbs 1 oz)
KP-61S65 1,338 x 1,506 X 642 mm
(52 2 / 4 x 5 9 ’ / 8 x 2 5 ^ / 8 inches)
122 kg
(268 lbs 15 oz)
KP-61S65C 1,338 X 1,506 X 642 mm
(52
^ / 4 X 59 ^/s X 25 ^/s inches)
122 kg
(268 lbs 15 oz)
Supplied accessories
Remote control RM-Y136A (1)
Size AA (R6) battery (2)
Optional accessories
U/V mixer EAC-66
Connecting cables RK-74A, VMC-810S/
820S, YC-15V/30V, VMC-720M
Stand SU-41T2 {For KP-41T65/KP-41T65C)
High-contrast protective screen
SCN-46X1 {For KP-46C65)
SCN-48X2 {For KP-48S65)
SCN-53X2 {For KP-53S65/KP-53S65C)
SCN-61X2 (For KP-61S65/KP-61S65C)
Design and specifications are subject to change without
notice.
Additional Information
I 39 -EN
