Identifying the Parts and Controls
Remote Commander (Except for The STR-D911
for Canadian Model)
Eh
E]—
a ^C3C3C]
i d o c d c i
O
CD
o o o
o o o
o o o
o o o
CD
CD
CD
CD
CD
CDCDCDCD
mi—1 m m 1—11—1
O
C3
0
O a
O
a a
O CD
O CD
-m
rn Receiver control section
FUNCTION buttons
DAT. CD. TUNER. PHONO. VIDEO 1. VIDEO 2. VIDEO
3. TAPE; The each function is selected and the each
unit enters its operating mode automatically.
SYSTEM OFF: Turns off the power of the whole system.
SOUND FIELD buttons
USER/PRE: This button does not function.
MODE: Selects the sound field mode.
ON/OFF: Turns on/off the sound field system.
BAND: This button does not function.
EQ: Turns on/off the setting of TONE controls.
T. (test) TONE: Generates a pink noise signal that is
sent in succession to each speaker.
CURSOR MODE: Select CURSOR MODE.
CURSOR operating buttons
REAR LEVEL +/- buttons: Control the volume of rear
speakers (surround level).
CENTER LEVEL +/- buttons: Control the volume of
center speaker (surround level).
DBFB button: Turns on/off the DBFS (Dynamic Bass
Feedback).
MUTING button; Mutes the sound.
MASTER VOL +/- buttons: Control the receiver
volume.
SLEEP: Set to the SLEEP timer mode. In this mode, the
unit is automatically turned off after the designated
time, (page 13)
Note
THe VIDEO 3 button functions only for the STR-D911.
m Other equipment control section
The operative buttons are changed according to the
function mode and the setting of the SYSTEM/TV
selector.
Numeric buttons (1 to 0): Designate the number.
>10; Designate the number more than 10.
ENTER: Press after designating the TV/VCR channel.
TV/VIDEO selector: Selects the TV program to see: TV
or VIDEO.
ANT TV/VTR button: Selects the output signal from the
antenna terminal on the VCR. either a TV signal or
VCR programs.
SHIFT: Select the memory page (A. B or C) only in the
TUNER mode.
CH/PRESET +1- buttons: Select a preset station of tuner
or a preset channel of TV/VCR.
INDEX: Select another index station.
◄ ◄ /► ► : fast winding/Manual search
•: Recording (Press • and or ► at the same time.)
◄ /► : Play
■ ; Stop
II: Pause
Locates a desired selection.
D (disc) SKIP: Disc skip (for a CD player equipped
with a multi-disc changer)
SELECT: Changes the settings of the FUNCTION
buttons.
VISUAL POWER: Turns on/off the power of TV. VCR and
LD player.
[H SYSTEM/TV mode switch
In TV mode (When setting the SYSTEM/TV selector
to TV.)
Only MUTING. M/VSTER VOL +/- and the operative
buttons in TV section on the list described on the next
page can be used.
10
