8
HIGH FLOW PUMP INSTALLATION
Hose Band
High flow pump
Rubber Cushion
Spacer
Screws
Sender unit modification
* Cut the pipe and
leave 27mm left.
* Remove any burrs.
27mm
Positive RED Negative BLACK
CONNECTING POWER TANK INSTALLATION
Check the mark.
Replace with a new
one
Φ5
39
15
* Replace the O-ring
with a new one.
* Make a "Mark" so
as not to confuse the
return hose and the
line to the engine.
* Drill a 5mm
hole in two places
as shown on the
left
* Remove any
burrs
