Assembly configuration, Installation, Caution – Tomei Powered HEAD STUD BOLTS User Manual
Page 6
ASSEMBLY CONFIGURATION
NUT (10)
WASHER (10)
[Exhaust Side Stud Bolts]
Stud Bolt Long Type (4)
[INTAKE Side Stud Bolts]
6
INSTALLATION
The illustration above shows where each bolt goes on the block.
Intake Side : Stud Bolt short type
Exhaust Side: Stub Bolt long type
Exhaust Side where the distributor is located: Stud Bolt with the special end
CAUTION
■ Refer to the Workshop Service Manual for detailed instructions on dissembling and reassembling the engine
and auxiliaries.
■ Note the length of each bolt prior to installation.
[Exhaust Side Stud Bolts]
Stud Bolt Long Type (4)
[INTAKE Side Stud Bolts]
Stud Bolt Short Type (5)
The Special End Type
stud bolt is used for this
corner of the block
6
