Software Controlled STORE/RECALL Cycle
Figure 11. Software STORE/RECALL CYCLE: E Controlled [13]
Figure 12. Software STORE/RECALL CYCLE: G Controlled
[13]
NO.
Symbols
Parameter
[12,13]
STK14CA8-35 STK14CA8-35 STK14CA8-45
Units Notes
E Cont G Cont Alt Min Max Min Max Min Max
26
t
AVAV
t
AVAV
t
RC
STORE/RECALL Initiation Cycle
Time 25 35 45 ns 13
27
t
AVEL
t
AVGL
t
AS
Address Setup Time 0 0 0 ns
28
t
ELEH
t
GLGH
t
CW
Clock Pulse Width 20 25 30 ns
29
t
EHAX
t
GHAX
Address Hold Time 1 1 1 ns
30
t
RECALL
t
RECALL
RECALL Duration 50 50 50
μs
26 26
27 28
29
23 30
26 26
27 28
29
23 30
Notes
12. The software sequence is clocked on the falling edge of E controlled READs or G controlled READs
13. The six consecutive addresses must be read in the order listed in the Software STORE/RECALL Mode Selection Table. W must be high during all six consecutive cycles.
