76 A d d i n g Pa r t s
www
.dell.com | support.dell.com
Make sure that the card is fully seated and that its bracket is within the
card slot.
7 Secure the bracket on the end of the card with the screw you removed
in step 5.
8 Connect any cables required for the card as described in the card
documentation.
9 Rotate the power supply back into place (see page 64).
10 Replace the computer cover (see page 80).
11 Plug your computer and devices into their electrical outlets, and turn
them on.
12 Install any drivers required for the card as described in the card
documentation.
fully seated not fully seated
bracket caught
outside of slot
bracket within slot
