Appendices 71
Table A.16: PM20i-20A IPDU and PM20i-L20A IPDU Electrical Specifications
Characteristics Specifications
Electrical
Input Voltage 100-240 VAC
Max Output Current Total 20A (de-rated to 16A)
Max Output Current Each Outlet 10A (de-rated to 8A)
Environmental
Operating Temperature 32-122 ºF (0-50 ºC)
Relative Humidity 5%-95%
Mechanical
Weight 17 lb. (7.73 kg)
Physical Dimensions (W x D x H) 2.0 x 2.8 x 66 in (5.18 x 7.11 x 167.6 cm)
Table A.17: PM20i-L30A Specifications
Characteristics Specifications
Electrical
Input Voltage 100-240 VAC
Max Output Current Total 30A (de-rated to 24A)
Max Output Current Each Outlet 10A (de-rated to 8A)
Environmental
Operating Temperature 32-122 ºF (0-50 ºC)
Relative Humidity 5%-95%
Mechanical
Weight 17 lb. (7.73 kg)
Physical Dimensions (W x D x H) 2.0 x 2.8 x 66 in (5.18 x 7.11 x 167.6 cm)
