Chapter 1: Introduction
11
•
Vertical mounting (zero U)
Figure 1.10: The Cyclades PM20i IPDU, PM20i-32A IPDU and PM20i-32AU IPDU
Cyclades PM20i-32A IPDU
The Cyclades PM20i-32A IPDU has the following features:
•
32A input power cord; IEC 309 plug.
•
Twenty 240VAC/10A power receptacles (IEC320-C13)
•
240VAC/two 16A magnetic circuit breakers with accidental-off protection function
•
Vertical mounting (zero U)
Refer to Figure 1.10 on page 11 for an image of the Cyclades PM20i-32A IPDU.
Cyclades PM20i-32Au IPDU
The Cyclades PM20i-32Au IPDU has the following features:
•
32A unterminated input power cord
•
Twenty 240VAC/10A power receptacles (IEC320-C13)
•
240VAC/two 16A magnetic circuit breakers with accidental-off protection function
•
Vertical mounting (zero U)
Refer to Figure 1.10 on page 11 for an image of the Cyclades PM20i-32Au IPDU.
