14 Configuring Your Managed System
www
.del
l.
com |
su
ppo
rt.
d
e
ll.
co
m
Using the System Setup Utility
1 Navigate to the Systems Management menu.
2 Navigate to the Console Redirection menu item and press .
3 Configure all Setup Console Redirection submenu items necessary for the method you have
chosen to access your managed system’s BMC. See Table 2-2 for a list of all valid Setup
Console Redirection submenu items. Default values, if applicable, are enclosed in brackets.
See Figure 1-1 for an overview of the necessary setup procedures.
4 Navigate to the Exit menu and select Exit Saving Changes. When prompted, select Yes to
save your changes and exit the utility.
Table 2-1. Using Setup Screens
Key Action
Left arrow Scroll left through the main menu screens
Right
arrow
Scroll right through the main menu screens
Enter Select a submenu item or accept a drop-down choice
Tab Select a field within a value (for example, date field)
F9 Select the default value
F10 Save your changes and exit Setup
ESC Go back to a previous screen
Up arrow Scroll up through menu items or value lists
Down
arrow
Scroll down through menu items or value lists
Table 2-2. Setup Console Redirection Submenu Items
Submenu Item Default Value Description
Serial Console
Redirection
Enabled
Disabled When enabled, Console Redirection uses only COM2.
Choosing Disabled completely disables Console
Redirection.
Baud Rate 9600
[19.2K]
38.4K
57.6K
115.2K
When Console Redirection is enabled, use the baud rate
specified. When the BMC Management Utility is
sharing the COM port as console redirection, the baud
rate must be set to 19.2K to match the utility’s baud
rate.
