System Beep Codes
When an error that cannot be reported on the monitor occurs during a boot routine, the system may emit a series of beeps that identify the problem.
When a beep code is emitted, record it on a copy of the Diagnostics Checklist in " Getting Help ," and then look it up in Table 2 -4 . If you are unable to resolve
the problem by looking up the meaning of the beep code, use system diagnostics to identify a more serious cause. If you are still unable to resolve the
problem, see "
Getting Help ."
Table 2-4. Server Module Beep Codes
Warning! Firmware is
out-of-date
Warning! Invalid board
serial number.
Corrupt NVRAM or the serial number
not programmed
See " Getting Help ."
Warning! No microcode
update loaded for
processor
New or unsupported microprocessor. Update the BIOS firmware, see " Getting Help ."
Write fault
Write fault on
selected drive
Faulty diskette, diskette/CD-drive
assembly, hard drive, or hard-drive
subsystem.
Replace the diskette. Replace the diskette/CD-drive subsystem. See " Removing the CD
and Diskette Drives " in "Installing Drives." If the problem persists, replace the faulty hard
drive. See " Hard Drives " in "Installing Drives."
NOTE: If the system boots without a keyboard, mouse, or monitor attached, the system will not issue beep codes related to those peripherals.
NOTE: Before you perform any procedures described in Table 2 -4 , see " Safety First— For You and Your System " in "Troubleshooting Your System."
Code Cause Corrective Action
1-1-2 CPU register test failure See " Troubleshooting the Microprocessor " in "Troubleshooting Your System."
1-1-3 CMOS write/read failure; faulty server
module board
Faulty system board. See " Getting Help ."
1-1-4 BIOS error Reflash the BIOS.
1-2-1 Programmable interval-timer failure;
faulty server module board
Faulty system board. See " Getting Help ."
1-2-2 DMA initialization failure See " Troubleshooting System Memory " in "Troubleshooting Your System."
1-2-3 DMA page register write/read failure
1-3-1 Main-memory refresh verification failure
1-3-2 No memory installed
1-3-3 Chip or data line failure in the first 64 KB
of main memory
1-3-4 Odd/even logic failure in the first 64 KB of
main memory
1-4-1 Address line failure in the first 64 KB of
main memory
1-4-2 Parity failure in the first 64 KB of main
memory
1-4-3 Fail-safe timer test failure
1-4-4 Software NMI port test failure
2-1-1
through
2-4-4
Bit failure in the first 64 KB of main
memory
3-1-1 Slave DMA-register failure Faulty system board. See " Getting Help ."
3-1-2 Master DMA-register failure
3-1-3 Master interrupt-mask register failure
3-1-4 Slave interrupt-mask register failure
3-2-2 Interrupt vector loading failure
3-2-4 Keyboard-controller test failure
