System Overview

Dell™ PowerEdge™ 7150 Systems User's Guide

The Dell™ PowerEdge™ 7150 system is a feature-rich, enterprise-class server that offers the highest performance, availability, scalability, manageability, and
investment protection features. This system provides a robust, reliable, rack-optimized platform on which corporate customers can deploy their mission-critical
applications.

This section describes the major hardware and software features of the computer system, provides information about the indicators on the system's bezel and control
panel, and discusses connecting external devices to the system. It also provides information on obtaining assistance from Dell.

Computer Orientation

When following the procedures in this guide, assume that the locations or directions relative to the computer are as shown in

Figure 1-1

Figure 1-1. Computer Orientation (top view)

Removing and Replacing the Bezel

Removing the front bezel provides access to the power switch, diskette drive, control panel, CD-ROM drive, power supplies, and hard-disk drive(s).

Removing the Bezel

Pull the bezel away from the computer until it disengages from the four posts on the chassis (see

Figure 1-2

Figure 1-2. Removing the Bezel
