Dell AX4-5 User Manual
Page 42
42
Cabling Your Blade Cluster Hardware
Figure 2-9. External Network-Attached Cluster With Embedded Fibre Channel Switch
Modules
1
Fibre Channel switch module in I/O
bay C1
2
Fibre Channel switch module in I/O
bay C2
1
2
CX3-80 storage system
PowerEdge M1000e system
book.book Page 42 Monday, December 31, 2007 3:41 PM
