10 Introduction
The power supply modules, fan modules, Dell Remote Access
Controller/Modular Chassis (DRAC/MC), and I/O modules are shared
resources of the server modules in the chassis. The system may ship with an
optional external Universal Serial Bus (USB) diskette drive and an optional
external USB CD drive, which you can use to set up and configure the server
modules.
For information on supported cluster configurations, see "Cabling Your Blade
Cluster Hardware" on page 25. For a list of supported hardware and software
components, see the Platform Guide for your PowerEdge cluster solution
located on the Dell Support website at support.dell.com.
NOTE: To ensure proper operation and cooling, all bays must be populated with
either a server module or a blank prior to turning on the system.
The PowerEdge server enclosure include the following hardware components
for a cluster configuration:
• Server modules
• Gigabit Ethernet switch modules or Gigabit Ethernet pass-through
modules (based on your configuration)
• Fibre Channel switch modules or Fibre Channel pass-through modules
(based on your configuration)
1 server module 8 I/O bay A2
2 power switch and KVM ports 9 I/O bay B2
3 control panel 10 I/O bay C2
4 DRAC/MC module 11 I/O bay C1
5 KVM module 12 I/O bay B1
6 fan module 13 I/O bay A1
7 power supply module
