Dell AX4-5 User Manual
Page 18
18
Introduction
Figure 1-5. Network-Attached Cluster Connected to an External SAN Using Embedded
Pass-Through Modules
cluster node
cluster node
private network
storage system
embedded pass-
through module
public network
external switch
embedded pass-
through module
external switch
book.book Page 18 Monday, December 31, 2007 3:41 PM
