8 Introduction
1 server module (10) 8 power supply module (4)
2 front-panel indicators 9 blanks (2)
3 Ethernet switch module or Ethernet
pass-through module (not shown) (2)
10 Ethernet switch module (2) or Ethernet
pass-through module (not shown) (2)
4 I/O bay 1 11 I/O bay 4
5 I/O bay 3 12 I/O bay 2
6 KVM module 13 fan modules (2)
7 DRAC/MC module
