Cabling Your Blade Cluster Hardware 37
Figure 2-6. Cluster Configuration Using Two PowerEdge Server Enclosures and One
Storage System
1 Ethernet switch module for iSCSI
traffic (2)
2 Ethernet switch module for cluster
network (2)
storage system SPs
private network connection
PowerEdge system 1 PowerEdge system 2
ISLs
ISLs 2
public network
1
