60
Operating the Axim
Using the Sync Cable
Use the sync cable to connect your device directly to the computer without
using the cradle.
NOTE:
The sync cable is optional depending on the configuration of your device.
To connect the sync cable:
1 Connect the sync cable connector to your device. Ensure that the Dell
logo is facing upwards.
2 Connect the USB connector of the cable to the USB connector on
your computer.
NOTICE:
To avoid damaging the sync cable connector, press the two buttons
on the sides of the connector to release the lock before inserting or pulling out
the connector.
power
cord
AC adapter
sync cable
USB connector
on the computer
device connector
sync cable connector
