Getting Started 49
4 Close the battery cover.
5 Lock the battery cover by sliding the battery lock to the right.
To remove the battery:
1 Slide the battery lock to the left to unlock the battery cover.
2 Lift the battery cover.
battery cover
battery lock
battery cover
battery lock
