Canon IMAGECLASS MF5700 User Manual
Page 26
Main Components of the Machine
1-5
In
tr
od
uctio
n
1
Rear View
a USB port
Connect the USB (Universal Serial Bus) cable.
b Ethernet port
Connect the network cable.
(Only for the MF5770 model.)
c Face up cover
Open it when you output paper face up, or
remove jammed paper.
d Power socket
Connect the power cord.
e External cover
Protects paper supply in the cassette from dirt
and dust.
c
d
e
b
a
