Replacing the USB Module
1.
Follow the procedures in
Before You Begin
.
2.
Align the hole on the USB module with the protrusion on the computer base.
3.
Replace the screw that secures the USB module to the computer base.
4.
Route the USB module cable and connect it to the system board connector.
5.
Replace the tape to secure the USB module cable to the battery extension board.
6.
Replace the palm rest (see
Replacing the Palm Rest
).
7.
Replace the keyboard (see
Replacing the Keyboard
).
8.
Replace the center control cover (see
Replacing the Center Control Cover
).
9.
Replace the memory module(s) (see
Replacing the Memory Module(s)
).
10.
Replace the module cover (see
Replacing the Module Cover
).
11.
Replace the optical drive (see
Replacing the Optical Drive
).
12.
Replace the hard drive (see
Replacing the Hard Drive
).
13.
Replace the battery (see
Replacing the Battery
).
Back to Contents Page
3 USB module
4 screw
5 tape
CAUTION:
Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
