Replacing the Battery Latch Assembly
1.
Follow the procedures in
Before You Begin
.
2.
Slide the battery latch assembly into place.
3.
Using a small screwdriver, place the latch spring over the hook on the computer base.
4.
Push the plastic clips on the battery release latch into the hole on the battery latch assembly to secure the battery release latch.
5.
Replace the palm rest (see
Replacing the Palm Rest
).
6.
Replace the keyboard (see
Replacing the Keyboard
).
7.
Replace the center control cover (see
Replacing the Center Control Cover
).
8.
Replace the memory module(s) (see
Replacing the Memory Module(s)
).
9.
Replace the module cover (see
Replacing the Module Cover
).
10.
Replace the optical drive (see
Replacing the Optical Drive
).
11.
Replace the hard drive (see
Replacing the Hard Drive
).
12.
Replace the battery (see
Replacing the Battery
).
Back to Contents Page
1
battery latch assembly
CAUTION:
Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
