Coin-Cell Battery
Dell™ Inspiron™ 17 Service Manual
Removing the Coin-Cell Battery
Replacing the Coin-Cell Battery
Removing the Coin-Cell Battery
1.
Follow the procedures in
Before You Begin
.
2.
Follow the procedures from
step 2
to
step 17
in
Removing the System Board
.
3.
Use a plastic scribe to pry out the coin-cell battery.
Replacing the Coin-Cell Battery
1.
Follow the procedures in
Before You Begin
.
2.
Hold the coin-cell battery with the positive (+) side facing up.
3.
Slide the coin-cell battery into the slot and gently press until it snaps into place.
4.
Follow the procedures from
step 5
to
step 20
in
Replacing the System Board
.
Back to Contents Page
WARNING:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION:
Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell™
is not covered by your warranty.
CAUTION:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
CAUTION:
To help prevent damage to the system board, remove the main battery (see
Removing the Battery
) before working inside the
computer.
1
coin-cell battery
2
system board
3
plastic scribe
CAUTION:
Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
