Display
Dell™ Inspiron™ 17 Service Manual
Display Assembly
Removing the Display Assembly
1.
Follow the procedures in
Before You Begin
.
2.
Remove the battery (see
Removing the Battery
).
3.
Remove the module cover (see
Removing the Module Cover
).
4.
Remove the memory module(s) (see
Removing the Memory Module(s)
).
5.
Remove the hard drive (see
Removing the Hard Drive
).
6.
Remove the optical drive (see
Removing the Optical Drive
).
7.
Remove the two screws from the computer base.
8.
Remove the center control cover (see
Removing the Center Control Cover
).
9.
Remove the keyboard (see
Removing the Keyboard
).
10.
Remove the palm rest (see
Removing the Palm Rest
).
11.
Remove the two screws that secure the display assembly to the computer base.
12.
Lift and remove the display assembly from the computer base.
WARNING:
Before working inside your computer, read the safety information that shipped with your computer. For additional safety best
practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance.
CAUTION:
Only a certified service technician should perform repairs on your computer. Damage due to servicing that is not authorized by Dell™
is not covered by your warranty.
CAUTION:
To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an unpainted metal
surface (such as a connector on your computer).
CAUTION:
To help prevent damage to the system board, remove the main battery (see
Removing the Battery
) before working inside the
computer.
