4. Replace the display assembly (see Replacing the Display Assembly ).
5. Follow the instructions from step 5 to step 21 in Replacing the System Board .
6. Replace the battery (see Replacing the Battery ).
Removing the Battery Lock Latch Assembly
1. Follow the procedures in Before You Begin .
2. Remove the battery (see Removing the Battery ).
3. Follow the instructions from step 3 to step 15 in Removing the System Board .
4. Remove the display assembly (see Removing the Display Assembly ).
5. Remove the screw that secures the battery lock latch to the battery lock latch assembly.
6. Lift the battery lock latch from the computer base.
Replacing the Battery Lock Latch Assembly
1. Follow the procedures in Before You Begin .
2. Hold the battery lock latch in place and replace the screw that secures the battery lock latch to the battery lock latch assembly.
3. Replace the display assembly (see Replacing the Display Assembly ).
4. Follow the instructions from step 5 to step 21 in Replacing the System Board .
5. Replace the battery (see Replacing the Battery ).
Back to Contents Page
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
1 battery lock latch 2 screw
3 battery lock latch assembly
CAUTION: Before turning on the computer, replace all screws and ensure that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
