Port designations are used, for example, in software installation procedures that
include a step in which you identify the port to which a printer is attached, thus telling
the software where to send its output. An incorrect designation prevents the printer
from printing or causes scrambled print.

USB connectors

video
connector

keyboard
connector

mouse
connector

serial port 2
connector

serial port 1
connector

NIC connector

parallel port
connector
