Coin-Cell Battery: Dell XPS M1710 Service Manual
file:///C|/Users/santhosh_v.ASIA-PACIFIC/Desktop/Hawke/New%20folder/coinbatt.htm[2/21/2014 11:23:55 AM]
1 coin-cell battery 2 release latch 3 battery cable connector
Replacing the Coin-Cell Battery
1. Install the replacement battery:
a. With the positive side up, insert the battery at a 30-degree angle under the release latch, and then push the
battery into place.
b. Connect the battery cable to the connector on the system board.
2. Replace the keyboard (see Keyboard ).
3. Replace the hinge cover (see Replacing the Hinge Cover ).
Back to Contents Page
