members of the team.
The association class IANet_NetworkVirtualAdapter contains no useful data - clients are really only interested in the endpoints
of this association. IANet_TeamedMemberAdapter does contain useful data about how the member adapter is used within the
team.
Task WQL Queries Result Class Comments
Enumerate
all teams
SELECT * FROM
IANet_TeamOfAdapters
IANet_TeamOfAdapters There is one instance of
IANet_TeamOfAdapters for each team.
This is equivalent to
IWbemServices::CreateInstanceEnumAsync.
Get the
virtual
adapter for
a team
ASSOCIATORS OF
{IANet_TeamOfAdapters path}
WHERE AssocClass =
IANet_NetworkVirtualAdapter
IANet_EthernetAdapter Returns only the adapter object for the
virtual adapter in the team. This adapter
will not exist if the team has been created
but Apply has not been called. (see below
on updating the configuration).
Enumerate
the team’s
member
adapters
ASSOCIATORS OF
{IANet_TeamOfAdapters path}
WHERE AssocClass =
IANet_TeamedMemberAdapter
IANet_EthernetAdapter Returns the adapters which are in the team,
but does not describe what role the adapter
plays.
Determine
an
adapter’s
role in a
team
REFERENCES OF
{IANet_EthernetAdapter path}
WHERE ResultClass =
IANet_TeamedMemberAdapter
IANet_TeamedMemberAdapter The class contains information about how
the member adapter relates to the team
and its current status within the team.
Back to Top
Getting the Team Settings
The setting objects are not associated with the team directly. In conformance with the CIM standard, they are associated with
a configuration object which is associated with the virtual IANet_EthernetAdapter for the team. The same configuration object
is also associated with the IANet_TeamOfAdapters object for the team.
The classes involved with this part of the schema are IANet_EthernetAdapter, IANet_TeamOfAdapters, IANet_Configuration,
IANet_SettingInt, IANet_SettingString, IANet_SettingEnum, IANet_SettingMultiSelection and IANetSettingSlider.
The association classes IANet_AdapterConfiguration and IANet_SettingContext do not contain any real data - they act as glue
between the settings and their parent object. This is exactly the same as the adapter settings case.
Task WQL Queries Result Class Comments
Get the
configuration object
for the team,
starting with the
virtual adapter
ASSOCIATORS OF
{IANet_EthernetAdapter
path} WHERE
ResultClass =
IANet_Configuration
IANet_Configuration Returns exactly one object. Even if there
are no settings, there will always be a
configuration object. The object path from
this object is used in the next query.
Get the
configuration object
for the team,
starting with the
team of adapters
ASSOCIATORS OF
{IANet_TeamOfAdapters
path} WHERE
ResultClass =
IANet_Configuration
Get the settings
associated with an
adapter
ASSOCIATORS OF
{IANet_Configuration
path} WHERE AssocClass
= IANet_SettingContext
A mixture of
IANet_SettingInt,
IANet_SettingString,
IANet_SettingEnum,
IANet_SettingMultiSelection,
Returns all the setting classes associated
with the adapter. The client should use the
__CLASS attribute to determine that type
of each setting.
