6

Your Dell Projector

About Your Projector

1

Power button

2

Temp LED

3

Lamp LED

4

IR receivers

5

Lamp cover

6

Camera

7

10 W speaker

8

Lens

9

Focus ring

10

Mounting holes for wall mount: Screw hole M4 x 8 mm depth.
Recommended torque <10 kgf-cm

163.00

112.50

38.80

151.30

10

7

4

5

9

3

6

7

8

2 1

Top View

Bottom View
