Connecting Your Projector
Connection With Commercial RS232 Control Box
NOTE:
The RS232 (9-pin D-sub female to female pin2-3 swap) cable
is not shipped with your projector. Consult a professional technician
to obtain the cable.
1
Power cord
2
RS232 (9-pin D-sub female to female
pin2-3 swap) cable
3
Commercial RS232 control box
3
2
1
