Replacing the display back-
cover
WARNING: Before working inside your computer, read the
safety information that shipped with your computer and
follow the steps in Before working inside your computer .
After working inside your computer, follow the instructions
in After working inside your computer . For more safety best
practices, see the Regulatory Compliance home page at
dell.com/regulatory_compliance.
Procedure
NOTE: This chapter is applicable only if you have purchased a laptop with
non-touchscreen display.
1 Replace the AlienFX AlienHead board.
2 Replace the AlienFX Display light.
3 Adhere the display-board and camera cable to the display back-cover.
4 Route the display-board cable through the routing guides on the display
back-cover.
5 Connect the camera cable to the camera module.
Post-requisites
1 Replace the Alienware AlienHead LED board .
2 Replace the display-panel AlienFX LEDs .
3 Replace the camera .
4 Replace the display panel .
5 Replace the display bezel .
6 Replace the display assembly .
7 Follow the procedure from step 5 to step 11 in “Replacing the palm rest ”.
8 Replace the wireless card .
9 Replace the base panel .
