simultaneously over eight separate lines. The port can be configured as a unidirectional (output-only) port for
devices such as a printer or as a bidirectional port for devices such as a network adapter.
lists the pin
assignments.
The computer's built-in parallel port is designated as LPT1. If you reconfigure your hardware, you may need pin
number and signal information for the serial connector. The Microsoft
®
Windows
®
95 and Windows 98 operating
systems automatically recognize the parallel device and configure it correctly. The parallel port can also be
configured for compatibility with the PS/2 standard.
Table 1. Parallel Port Pin Assignments
Pin
Signal
I/O
Definition
Pin
Signal
I/O
Definition
1
STB#
O
Strobe
11
BUSY
I
Busy
2
PD0
I/O
Parallel data bit 0
12
PE
I
Paper end
3
PD1
I/O
Parallel data bit 1
13
SLCT
I
Select
4
PD2
I/O
Parallel data bit 2
14
AFD#
O
Automatic feed
5
PD3
I/O
Parallel data bit 3
15
EFF#
I
Error
6
PD4
I/O
Parallel data bit 4
16
INIT#
O
Initialize printer
7
PD5
I/O
Parallel data bit 5
17
SLIN#
O
Select in
8
PD6
I/O
Parallel data bit 6
18-25
N/A
N/A
Signal ground
9
PD7
I/O
Parallel data bit 7
Shell
N/A
N/A
Frame ground
10
ACK#
I
Acknowledge
USB Connector
The USB connector supports the use of a USB hub device to attach multiple devices. USB devices are typically
low-speed peripherals such as mice, keyboards, printers, and computer speakers. The C/Port APR and C/Dock
Expansion Station have two USB connectors.
NOTE: If you are using a USB external keyboard, do not enter the System Setup program by using a
keyboard command on the external keyboard. Instead, press
Serial Connector
Use the 9-pin serial connector to attach a serial device to the computer.
lists the pin assignments.
The serial port passes data in serial format (one bit at a time over one line). This port supports a variety of
devices that require serial data transmission, including a serial mouse, serial printer, plotter, or external modem.
If you reconfigure your hardware, you may need pin number and signal information for the serial connector.
