Dell Inspiron 8200 - Manual (Page 57)

supports composite video and S/PDIF)
Modem RJ-11 port
Network adapter RJ-45 port
IEEE 1394 4-pin serial connector
Communications
Modem:
Type integrated v.92 56K
Controller softmodem
Interface internal AC 97 bus
Network adapter 10/100 Ethernet LAN on system board
Wireless internal Mini PCI Wi-Fi (802.11b) wireless support
Video
Video type 128-bit hardware accelerated
Data bus 4X AGP
Video controller NVIDIA GeForce4 440 Go™
ATI Mobility™ RADEON™ 9000
Video memory NVIDIA GeForce4 440 Go™
ATI Mobility™ RADEON™ 9000
LCD interface LVDS
TV support NTSC or PAL in S-video and composite modes
Audio
Audio type AC97 (Soft Audio)
Audio controller Cirrus Logic/Crystal CS4205
Stereo conversion 18-bit analog-to-digital
20-bit digital-to-analog
Interfaces:
Internal AC 97
External microphone-in connector, stereo
headphones/speakers connector, and stereo line-in
connector
Speaker two 4-ohm speakers
Internal speaker amplifier 1.9 W per channel into 4 ohms
Volume controls keyboard shortcuts, program menus
Display
Type (active-matrix TFT) SXGA+, UXGA, or Enhanced UXGA
Dimensions:
Height 228.1 mm (9 inches)
Width 304.1 mm (12 inches)
Diagonal 380.1 mm (15 inches)
Maximum resolutions 1400 x 1050 at 16.8 million colors (SXGA+)
1600 x 1200 at 16.8 million colors (UXGA and
Enhanced UXGA)
Response time (typical) 20-ms rise (maximum) (SXGA+ and UXGA)
30-ms fall (maximum) (SXGA+ and UXGA)
9-ms rise (maximum) (Enhanced UXGA)
16-ms fall (maximum) (Enhanced UXGA)
Refresh rate 60 Hz
Operating angle 0º (closed) to 180º
Pixel pitch 0.20 x 0.20 mm (SXGA+)
0.19 x 0.19 mm (UXGA and Enhanced UXGA)
Controls brightness can be controlled through keyboard
shortcuts
Keyboard
Number of keys 87 (U.S. and Canada); 88 (Europe); 90 (Japan)
Key travel 2.7 mm ± 0.3 (0.11 inch ± 0.016 inch)
Key spacing 19.05 mm ± 0.3 mm (0.75 inch ± 0.012 inch)
Layout QWERTY/AZERTY/Kanji
